How to Implement SignalR in .NET Core Web App

March 3, 2025

The Intro- Whats SignalR?

SignalR is an open-source library developed by Microsoft that enables real-time communication between servers and clients in web applications.

What’s so special?

Traditional web applications follow a request-response model, where the client requests data, and the server responds. SignalR transforms this paradigm by allowing servers to push updates to clients proactively, facilitating instantaneous data synchronization. Like a real chaaat!

Key Features of SignalR:

Real-Time Communication: Supports bidirectional communication, enabling servers and clients to exchange messages with minimal latency.
Automatic Protocol Management: Automatically selects the most efficient transport protocol (WebSocket, Server-Sent Events, or Long Polling) based on client and server capabilities.
Group Management: Allows the creation and management of groups of connections, facilitating targeted broadcasting of messages to specific user sets.
Cross-Platform Support: Compatible with various languages, including JavaScript, .NET, and Java, making it suitable for cross-platform real-time applications.
Security: Offers built-in authentication and authorization mechanisms, ensuring secure communication channels protected by encryption and digital signatures, if needed.

Implementing SignalR in .NET Core:

To integrate SignalR into an ASP.NET Core MVC project, follow the below steps:

Prerequisites

.NET 8 SDK
Visual Studio 2022

1. Install SignalR NuGet Package:

Use the Package Manager Console or NuGet Package Manager to install the SignalR package:

dotnet add package Microsoft.AspNetCore.SignalR

2. Add SignalR Middleware:

In the Program.cs file, incorporate SignalR services and map the SignalR hub:

var builder = WebApplication.CreateBuilder(args);

// Add SignalR services builder.Services.AddSignalR();

var app = builder.Build();

// Map the SignalR Hub app.MapHub("/IntertoonsChatHub");

app.Run();

3. Create a Hub:

Define a Chat Hub class that inherits from Hub and implements methods for client-server communication:

using Microsoft.AspNetCore.SignalR; using System.Threading.Tasks;

public class IntertoonsChatHub : Hub {
public async Task SendMessage(string user, string message) {
await Clients.All.SendAsync("ReceiveMessage", user, message); }
}

4. Add Client-Side Scripts:

Include the SignalR JavaScript client library in your view, either via a CDN or by installing it locally:

<!-- Reference SignalR library -->

<script src="https://cdnjs.cloudflare.com/ajax/libs/microsoft-signalr/5.0.9/signalr.min.js"></script>

5. Create a View for Real-Time Communication:

Develop a simple chat interface in your Razor view:

<div id="messagesList"></div>
<input type="text" id="userInput" placeholder="Enter your name" />
<input type="text" id="messageInput" placeholder="Enter a message" />
<button onclick="sendMessage()">Send</button>

<script>
    const connection = new signalR.HubConnectionBuilder().withUrl("/IntertoonsChatHub").build();

    connection.on("ReceiveMessage", (user, message) => {
        const msg = document.createElement("div");
        msg.textContent = `${user}: ${message}`;
        document.getElementById("messagesList").appendChild(msg);
    });

    connection.start().catch(err => console.error(err.toString()));

    function sendMessage() {
        const user = document.getElementById("userInput").value;
        const message = document.getElementById("messageInput").value;
        connection.invoke("SendMessage", user, message).catch(err => console.error(err.toString()));
    }
</script>

6. Run the Application:

Launch your application and navigate to the appropriate view to test the real-time chat functionality.

By following these steps, you can implement real-time communication in your .NET Core application using SignalR, enhancing user engagement and interactivity.
